Tính năng của sản phẩm:
| Ports: | 2xEthernet; 1xCAN |
| CAN protocol | CAN 2.0A and CAN 2.0B |
| BACnet protocol | BACNet IP Slave |
| Data Rates CAN | Up to 1 Mbps |
| Data Rates BACnet | 10/100 Base-T Autosensing |
| CAN connector | 3way 5mm terminal block |
| BACnet connector | RJ45 |
| Power supply | 8..24V AC; 12..35V DC |
| Power supply connector | 2way 5mm terminal block |
| Operating temperature | -40° to +85° (-40°F to +185°F) |
| Dimensions | 120x23x107 (DxWxH) |
| Weight | 200g approx |
| Mechanical fixing | 35mm DIN Rail montage |
| Software | SW67677 |
